What are Inverters & Converters?

My (Just Ask Mike) JAM Session on the difference… (Dec 2023)

Dear Mike,

I’m a newbie so please be gentle with me. I keep hearing about inverters and converters, but I’m confused as to the difference. Can you explain what they are in simple language?

Thanks… Tony

Dear Tony,

Yes, RV terminology can be very confusing for a newbie. After all, your house doesn’t have a converter or an inverter or house batteries. In a bricks and sticks house you just plug in and go. But in an RV you have to think about running from 120-volt AC power or 12-volt DC power, and that’s where inverters and converters come in.

Basically, most of the smaller gadgets in your RV (interior lighting, television, ventilation fans, water pump, etc.) all run from 12 volts DC. Yes, this is exactly like the 12 volts DC from your car battery that powers the headlights, radio, blower motor, etc. And your car has a way to recharge its battery whenever the engine is running. This is called the alternator, which is belt-driven from the engine. Without an alternator to recharge your car battery it would soon be dead.

What about your RV?

Your RV does something similar, with a 12-volt DC storage battery (called the house battery) and a set of fuses and/or circuit breakers to feed power to your fans, lights, television, etc. But instead of an alternator driven by the car engine to recharge this house battery, at the minimum you’ll have something called a converter. Its job is to take 120 volts AC from the pedestal or outlet that your shore power cord is plugged into, and “convert” it down to 12 volts DC or so (actually, a little closer to 14 volts, but who’s counting?). This is so that it can do two things: recharge your house battery (or batteries), and provide power to run the aforementioned 12 volt DC accessories such as your RV lights, fans, etc. With me so far?

Now, not all of your RV accessories will run from 12 volts DC. Some insist on needing 120 volts AC at 60 Hz to operate, just like you get from a wall outlet in your home. One big example would be a residential refrigerator showing up in many larger RVs. If your RV is plugged into shore power it’s no big deal. But what if you’re boondocking (camping without campsite electricity or water supply) and don’t want to start up a generator for 120-volt AC power?

Enter the Inverter

Since these bigger appliances won’t run on 12 volts DC directly from your house battery, you need something that will “invert” the 12 volt DC battery power into 120 volt AC power. And yes, it’s called an inverter. Its job is to make 120 volts AC for the larger appliances in your RV – that might also include things like your microwave oven and large-screen television. However, there’s no cheap way to install enough batteries in an older RV to run a rooftop air conditioner for more than an hour before the battery goes dead. But a properly designed battery and inverter installation can run an air conditioner for 5 hours or more. I know, because I have such a MasterVolt system on my GeoPro trailer.

So, a “converter” converts the 120-volt AC power from the campground pedestal into 12 volts DC to charge your RV’s house battery (or batteries) as well as run all of your DC appliances. An “inverter” does the opposite and inverts the 12-volts DC from the RV’s house battery into 120-volts AC that bigger appliances such as your residential refrigerator and microwave oven can use.

Don’t run out of Juice!

But don’t go crazy with running lots of appliances at once when you’re operating on battery power alone since you’ll soon run out of juice.

What about chargers?

More on this later, but I’ll do a deep dive on how battery charging actually works. And yes, it’s a bit more complicated….

OK, everyone. Remember that electricity is a useful and powerful force, so we all need to pay attention to safety precautions while using it.

Let’s play safe out there…. Mike
